Honeywell UDC2800 controller Sepcification_사양서
The UDC2800 Universal Digital Controller packs new powerful features in the popular 1/4 DIN size.
UDC2800은 DIN1/4(96x96mm)사이즈의 강력하고 신특징을 갖는 디지탈 콘트롤러입니다.
OVERVIEW(개요)
Unmatched application power includes a Bluetooth Configuration interface, two universal analog inputs, and a Math Algorithm. When these components are combined with Accutune IIITM tuning with fuzzy logic overshoot suppression, the result is price/performance leadership. Application flexibility is assured by the universal analog inputs, universal AC power supply, two digital inputs, a maximum of two analog inputs and four digital outputs, RS485 Modbus RTU or Ethernet 10/100M Base-T TCP/ IP communication protocols, simple configuration plus total field upgrade capability for any optional feature.
스마트폰(iOS, Android)에서 설정이 가능한 블루투스 인터페이스 탑재, 두 개의 유니버설 멀티입력과 다기능의 산술 연산을 보유하고 다양한 어플리케이션에 적합한 솔루션을 제공합니다.
이러한 특징은 하니웰의 선진기술인 ACCUTUNE III 알고리즘에 기반하고 퍼지로직으로 오버슈트 또는 언더슈트를 방지하는 혁신적인 기술을 제공하여 결과적으로 가격대비 월등한 성능을 제공합니다.
또한 두개의 디지탈 입력과 최대 2개의 아날로그 입력, 최대 4개의 디지탈 출력 (경보포함), RS485 Modbus RTU 또는 이더넷(10/100Mbps TCP/IP) 통신과 간단한 설정에 더해 현장에서 요구하는 조건/동작을 위한 종합적인 업그레이드(아날로그 정밀도, 펌웨어 안정화)을 제공합니다.
